Creating a Simple DSL in Perl

Let’s look at the XSPF playlist format. It’s a pretty simple XML-based file format.

  <?xml version="1.0" encoding="UTF-8"?>
  <playlist version="1" xmlns="http://xspf.org/ns/0/">
    <title>80's Music</title>
    <trackList>
      <track>
        <title>Take On Me</title>
        <creator>A-ha</creator>
        <location>https://example.com/music/01.mp3</location>
      </track>
      <track>
        <title>Tainted Love</title>
        <creator>Soft Cell</creator>
        <location>https://example.com/music/02.mp3</location>
      </track>
      <track>
        <title>Livin' on a Prayer</title>
        <creator>Bon Jovi</creator>
        <location>https://example.com/music/03.mp3</location>
      </track>
      </track>
    </trackList>
  </playlist>

The full specification has a lot more details, but for now, we’ll just use those elements.

If we are building a Perl application that needs to allow less experienced users to write playlists in Perl, it might be useful to define a domain-specific dialect of Perl for writing playlists.

Something like this:

  my $pl = playlist {
    title "80's Music";
    track {
      location "https://example.com/music/01.mp3";
      title "Take On Me";
      creator "A-ha";
    };
    track {
      location "https://example.com/music/02.mp3";
      title "Tainted Love";
      creator "Soft Cell";
    };
    track {
      location "https://example.com/music/03.mp3";
      title "Livin' on a Prayer";
      creator "Bon Jovi";
    };
  };

It is actually pretty simple to do this!

The `playlist` function

A simple implementation of the playlist function is this:

  my $current_playlist;

  sub playlist (&) {
    my $block = shift;
    $current_playlist = {};
    $block->();
    return $current_playlist;
  }

The prototype of (&) allows a function to accept a block of code. Our playlist function wants to create a blank playlist (which we’ll implement as an empty hashref), run the block (which will define the tracks), and then return the playlist.

The reason that the $current_playlist variable is declared outside the function is so that other functions (such as title) can access it.

Here’s an implementation for title:

  sub title ($) {
    my $string = shift;
    $current_playlist->{title} = $string;
    return;
  }

And we’ll use Exporter::Shiny to export our functions. Other exporters also exist.

  use Exporter::Shiny qw( playlist title );

Let’s test it:

  use XML::XSPF -all;
  use Test2::V0;

  my $pl = playlist {
    title "Test 123";
  };

  is( $pl, { title => "Test 123" } );

  done_testing;

Yay! It works!

Some sanity checks

We should add some checks to make sure title is only ever used inside a playlist, and also ensure that playlists are not nested.

  use Carp qw( croak );
  use Scope::Guard qw( guard );

  my $current_playlist;

  sub playlist (&) {

    my $block = shift;

    $current_playlist and croak( "Nested playlist" )
    $current_playlist = {};
    my $guard = guard { undef $current_playlist };

    $block->();

    return $current_playlist;
  }

  sub title ($) {

    my $string = shift;

    $current_playlist or croak( "Title outside playlist" );

    $current_playlist->{title} = $string;
    return;
  }

Using a guard to undef $current_playlist at the end of building a playlist ensures it will always happen, even if the block throws an exception, so we never end up with $current_playlist remaining dirty at the end of a playlist block.

Expanding on all that

Expanding upon these ideas to also provide track, creator, and location functions, we get:

  use 5.010001;
  use strict;
  use warnings;

  package XML::XSPF;

  # Utility functions we need.
  use Carp qw( croak );
  use Scope::Guard qw( guard );

  # Functions we will export.
  use Exporter::Shiny qw(
    playlist
    track
    title
    creator
    location
  );

  # Scratchpad for storing playlists and tracks while they are
  # being built.
  my $current_playlist;
  my $current_track;

  # Function called to define a new playlist.
  sub playlist (&) {

    # It accepts a block of Perl code (which will define tracks, etc).
    my $block = shift;

    # Ensure that there isn't already a half-built playlist, and then
    # start building one. The guard ensures that the playlist will be
    # cleaned up at the end of this function, even if an exception gets
    # thrown later.
    $current_playlist and croak( "Nested playlist" );
    $current_playlist = {};
    my $guard = guard { undef $current_playlist };

    # Run the block we were given.
    $block->();

    # Return the complete playlist.
    return $current_playlist;
  }

  # Function called to define a new track.
  sub track (&) {

    # It accepts a block of Perl code (which will add track details).
    my $block = shift;

    # Ensure that there isn't already a half-built track, and we haven't
    # been called outside a playlist, and then start building a track.
    # The guard ensures that the track will be cleaned up at the end of
    # this function, even if an exception gets thrown later.
    $current_track and croak( "Nested track" );
    $current_playlist or croak( "Track outside playlist" );
    $current_track = {};
    my $guard = guard { undef $current_track };

    # Run the block we were given.
    $block->();

    # Add the built track to the playlist. Return nothing.
    push @{ $current_playlist->{trackList} //= [] }, $current_track;
    return;
  }

  # Function to set the title for current track or playlist.
  sub title ($) {

    # It accepts a string.
    my $string = shift;

    # If there's a track being built, that's the target. Otherwise,
    # the target is the playlist being built. It's an error to call
    # this function if neither is being built.
    my $target = $current_track // $current_playlist;
    $target // croak( "Title outside playlist or track" );

    # Set the title. Return nothing.
    $target->{title} = $string;
    return;
  }

  # Function to set the location for current track.
  sub location ($) {

    # It accepts a string.
    my $string = shift;

    # It's an error to call this function if no track is being built.
    $current_track // croak( "Location outside track" );

    # Set the location of the current track. Return nothing.
    $current_track->{location} = $string;
    return;
  }

  # Function to set the creator for current track.
  sub creator ($) {

    # It accepts a string.
    my $string = shift;

    # It's an error to call this function if no track is being built.
    $current_track // croak( "Creator outside track" );

    # Set the creator of the current track. Return nothing.
    $current_track->{creator} = $string;
    return;
  }

  1;

And here’s a simple test:

  use Test2::V0;
  use Data::Dumper;
  use XML::XSPF -all;

  my $pl = playlist {
    title "80's Music";
    track {
      location "https://example.com/music/01.mp3";
      title "Take On Me";
      creator "A-ha";
    };
    track {
      location "https://example.com/music/02.mp3";
      title "Tainted Love";
      creator "Soft Cell";
    };
    track {
      location "https://example.com/music/03.mp3";
      title "Livin' on a Prayer";
      creator "Bon Jovi";
    };
  };

  is(
    $pl,
    {
      title => "80's Music",
      trackList => [
        {
          creator  => "A-ha",
          location => "https://example.com/music/01.mp3",
          title    => "Take On Me",
        },
        {
          creator  => "Soft Cell",
          location => "https://example.com/music/02.mp3",
          title    => "Tainted Love",
        },
        {
          creator  => "Bon Jovi",
          location => "https://example.com/music/03.mp3",
          title    => "Livin' on a Prayer",
        },
      ],
    },
  ) or diag Dumper( $pl );

  done_testing;

If you try it out, it should pass.

Next steps

A good next step might be for playlist to build a blessed XML::XSPF::Playlist object, and track to build blessed XML::XSPF::Track objects. XML::XSPF::Playlist could offer a to_xml method.

These improvements are left as an exercise to the reader.
